60
37.1 GPI 1 OUT
Setting of this parameter determines what (if any) FS1 event will generate a GPI
trigger output at GPI 1, pin #3 on DE-9.
37.2 GPI 2 OUT
Setting of this parameter determines what (if any) FS1 event will generate a GPI
trigger output at GPI 2, pin #4 on DE-9.
40.1 Freeze Output
This parameter tells the FS1 to freeze the current video frame on all outputs. This
may be useful for either testing or in case of loss of the input source.
Note: The freeze feature can be controlled not only by the front-panel and Web
browser interface, but also by GPI. When GPI is causing the freeze condition, the
AUX lamp will be lit on the front-panel.
37.1 GPI 1 OUT Description of Choices
Parameter Adjustments:
No Action (Default)
Alarm
No Video
No Ref
FS1 will not trigger a GPI 1 output trigger regardless of event
FS1 will generate a GPI 1 output trigger on pin#3 if an internal alarm condition
occurs
FS1 will generate a GPI 1 output trigger on pin#3 if no video is detected at its
selected input
FS1 will generate a GPI 1 output trigger on pin#3 if no video is detected at its
Ref video input
39.1 GPI 2 OUT Description of Choices
Parameter Adjustments:
No Action (Default)
Alarm
No Video
No Ref
FS1 will not trigger a GPI 2 output trigger regardless of event
FS1 will generate a GPI 2 output trigger on pin#4 if an internal alarm condition
occurs
FS1 will generate a GPI 2 output trigger on pin#4 if no video is detected at its
selected input
FS1 will generate a GPI 2 output trigger on pin#4 if no video is detected at its
Ref video input
40.1 Freeze Output Description of Choices
Parameter Adjustments:
OFF (Default)
ON
Normal operation. The FS1 outputs video from the input.
The FS1 captures and freezes the most current video frame and displays it on the
outputs as long as this parameter is set to ON.
