FS1 Installation and Operation Manual — 2.12 Audio Map Ch2

Note:

If parameter 4.5 Audio Follow Video is set to ON, then Audio Map Ch1

selection is independently kept for each separate input: SDI 1, SDI 2, Composite, S-
Video, and Component. If Audio Follow Video is set to OFF, then another Audio Map
Ch1 selection is used. This note applies to Parameters 2.11 through 2.18.

2.12 Audio Map Ch2

This parameter is used with parameter 2.2—when “Channel Map” is selected—to
specify the source of the audio output on channel 2. Possible choices are the same as
parameter 2.11. Default = AES Ch 2.

2.13 Audio Map Ch3

This parameter is used with parameter 2.2—when “Channel Map” is selected—to
specify the source of the audio output on channel 3. Possible choices are the same as
parameter 2.11. Default = AES Ch 3.

2.14 Audio Map Ch4

This parameter is used with parameter 2.2—when “Channel Map” is selected—to
specify the source of the audio output on channel 4. Possible choices are the same as
parameter 2.11. Default = AES Ch 4.

2.15 Audio Map Ch5

This parameter is used with parameter 2.2—when “Channel Map” is selected—to
specify the source of the audio output on channel 5. Possible choices are the same as
parameter 2.11. Default = AES Ch 5.

2.16 Audio Map Ch6

This parameter is used with parameter 2.2—when “Channel Map” is selected—to
specify the source of the audio output on channel 6. Possible choices are the same as
parameter 2.11. Default = AES Ch 6.

2.17 Audio Map Ch7

This parameter is used with parameter 2.2—when “Channel Map” is selected—to
specify the source of the audio output on channel 7. Possible choices are the same as
parameter 2.11. Default = AES Ch 7.

2.18 Audio Map Ch8

This parameter is used with parameter 2.2—when “Channel Map” is selected—to
specify the source of the audio output on channel 8. Possible choices are the same as
parameter 2.11. Default = AES Ch 8.
