4
FS1 Simplified Block Diagram
What ’ s In The Box?
When you unpack your AJA FS1 chassis, you’ll find the following components:
• AJA FS1 Chassis
• AC Power cords (2).
• The manual you’re reading (on CD).
• Optional: Late-breaking News or Read-Me-First notices (where applicable,
AJA may include additional bulletins related to your product and software).
Genlock
Audio
Embed
Audio
Embed
Front
Panel
Control
FS1
CPU
Embedded
Web
Server
LAN or
WAN
Ethernet
Connection
Remote Web
Browser
Control
SNMP
Remote Control Panel
VTECS
Video
Select
Audio
Select
SD/HD SDI In (#1)
SDI 1
SDI 2
AES/EBU
Analog
SD/HD SDI In (#2)
Component YPbPr In
S-Video In
Composite In
SD-SDI Out or
HD-SDI Out (#1)
SD-SDI Out or
HD-SDI Out (#2)
Component YPbPr or
RGB Out
S-Video Out
Composite Out
GPI
Inputs
(2)
GPI
Outputs
(2)
Ref
Loop
Ref
Input
Norm
Bypass
Bypass
Downconvert 2
Downconvert 2
Norm
AES/EBU Digital
Audio
Input
8-channels
AES/EBU digital
Audio
8-channels
Analog Audio
Input
8-channels
(Tascam-style cable)
Analog Audio
Output
8-channels
(Tascam-style cable)
Framesync
Up/Down/Cross
Converter,
Framesync,
ARC 1
Down
Converter 2,
Framesync,
ARC 1
ARC 1 = Aspect Ratio Converter
RS422
Port
(reserved for
future use)
Audio
Processor
Notes:
Other FS1s
