63 FS1 Installation and Operation Manual — 50.6 MAC Address
50.6 MAC Address
Selecting this parameter allows you to view the FS1 MAC address. The MAC address
is a unique value associated with the FS1’s internal network adapter. MAC addresses
are also known as hardware addresses or physical addresses. MAC addresses uniquely
identify an ethernet adapter on a LAN.
MAC address format: MM:MM:MM:SS:SS:SS
The value is 12-digit hexadecimal, where the first half identifies the manufacturer and
the second half identifies the unique serial number.
51.1 SNMP Enable
This parameter turns ON and OFF all SNMP messaging between the FS1 and an
external client. Refer to Chapter 6 for a description of SNMP and how the FS1
supports it.
When SNMP is enabled, one or more of 4 alarms may be sent by the FS1 as a trap
message:
Power supply failure or disconnection: fs1PSAlarm (see parameter 60.1)
Reference video: fs1REFAlarm (see parameter 60.3)
Format: fs1FMTAlarm (see parameter 60.2)
Temperature of FS1 is over limit (internally): fs1OVRAlarm
Note: With SNMP parameters 51.1 through 51.6, there is no timeout when
editing—changes made while in these menus will be saved and activated when the
menu is exited. For example, changing from Disable to Enable 1 does not turn SNMP
on. You must exit the 51.1 SNMP Enable parameter menu in order to turn SNMP
on.
50.5 System Name Description of Choices
Parameter Adjustments:
variable Using the adjust buttons, enter a name for the FS1. Using the adjust buttons and
the top Select button, select the characters for each of the up to 20-character name.
The adjust buttons scroll through the choices and the top Select button advances to
the next character. While selecting characters, the character being changed will
flash to show its position. The character set allowed is: '-', '.', A through Z
(uppercase) and a through z (lowercase).
Default: aja-fs1
51.1 SNMP Enable Description of Choices
Parameter Adjustments:
Disable (Default)
Enable 1
Enable Both
When set to Disable, the FS1 will not issue SNMP trap messages.
When set to Enable 1, the FS1 issues SNMP trap messages to Trap Destination 1
(parameter 51.2) and as defined in the MIB.
When set to Enable Both, the FS1 issues SNMP trap messages to Trap Destination
1 and 2 (parameters 51.2 and 51.4) and as defined in the MIB.
