2
•
Composite/S video input and output with TBC
•
8 Channel AES and balanced analog audio inputs and outputs
•
16 Channel embedded audio passed to SDI outputs
•
Audio mapping and control with AFV (audio follows video)—
16 channels embedded audio can be mapped to any 8
•
Fully redundant power supplies standard
•
10/100 LAN with SNMP, embedded web server for remote control, and
VTECS™ open protocol
•
Video Proc Amp
•
Closed caption support – including SD to HD upconversion
•
Chassis styling optimized for use in a wide variety machine rooms, with
simple panel and remote web browser user interfaces
•
Front panel alphanumeric and graphical display shows input and output
settings, and is also used for parameter viewing/editing
•
LED status indicators for at-a-glance system monitoring
•
Two GPI inputs and outputs, TTL, isolated
•
Sidebar Keyer
•
5-year international warranty, with unlimited technical support
FS1 Front Panel Control
FS1 operation can be monitored and changed in a number of ways:
•
Front panel control
•
Remote web browser via Ethernet
•
VTECS protocol via Ethernet
•
SNMP monitoring (Simple Network Management Protocol)
Feature sets in each of the control methods vary, although the Front Panel and
Web Browser interfaces offer much of the same features.
The front panel offers the most direct control of the device, ideally for use in
machine rooms or where quick and fast changes and status checks must
sometimes be made.
Chapter 2, Controls and Indicators
discusses the front and rear
panel features of the panel in great detail.
Remote Web Browser Control of FS1 via Ethernet
The FS1 internally contains an optimized web server that allows remote
monitoring and parameter setting via a network-attached computer running a
web-browser.
