39 FS1 Installation and Operation Manual — 3.1 Component In Format
3.1 Component In Format
This parameter configures the format of the Component video input.
3.2 Component Out Format
This parameter configures the format of the Component video output.
3.3 Frame Rate
This parameter selects the HD video frame rate associated with the video standard.
Note: Changing the Frame Rates selection automatically selects a new value for 1.1
Output Format. Each “Frame Rates” selection remembers its own Output Format
settings.
3.4 NTSC Standard
This parameter selects the NTSC video standard.
3.1 Component In Description of Choices
Parameter Adjustments:
Beta YPbPr
SMPTE YPbPr (Default)
Configure the Component video input source as Beta YPbPr (Standard Definition)
(If the selected Component video source is HD, this will default to SMPTE YPbPr)
Configure the Component video input source as SMPTE YPbPr
3.2 Component Out Description of Choices
Parameter Adjustments:
Beta YPbPr
SMPTE YPbPr (Default)
RGB
Configure the Component video output as Beta YPbPr (Standard Definition)
(If the Component video is HD, this will default to SMPTE YPbPr)
Configure the Component video output as SMPTE YPbPr
Configure the Component video output as RGB
3.3 Frame Rate Description of Choices
Parameter Adjustments:
59.94/23.98 (Default)
60/24
50/25
Select the “59.94/23.98” item if your desired rate is either 59.94 or 23.98
Select the “60/24” item if your desired rate is either 60 or 24
Select the “50/25” item if your desired rate is either 50 or 25 (PAL)
3.4 NTSC Standard Description of Choices
Parameter Adjustments:
NTSC (Default)
NTSC Japan
Select NTSC for North America NTSC standard.
Select NTSC Japan for Japan’s NTSC standard.
