Rockwell Automation Publication GMC-RM008A-EN-P - September 2011
53
Ultra3000 Drive Systems
Ultra3000 Drives with MP-Series Electric Cylinders
This section provides system combination information for the Ultra3000 drives when matched with MP-Series electric
cylinders. Included are power/brake and feedback cable catalog numbers, system performance specifications, and the
optimum force/velocity curves.
Electric Cylinder Cable Combinations
For cable configuration illustrations and feature descriptions, by catalog number, refer to 2090-Series Motor/Actuator Cables Overview beginning on
.
Motor-end connector kits, and panel-mounted breakout components (drive end), are available for motor power/brake and feedback cables. Refer to Optional Drive Accessories on
.
Cable length xx is in meters. Refer to the Kinetix Motion Accessories Technical Data, publica
, for standard cable lengths.
Electric Cylinders
Motor Power/Brake Cable
Motor Feedback Cable
(1)
(1) Use drive-mounted breakout board (catalog number 2090-UXBB-DM15) with flying-lead cables on the drive end. Refer to Required Drive Accessories on
MPAR-A/B1xxxB
MPAR-A/B1xxxE
MPAR-A/B2xxxC
MPAR-A/B2xxxF
2090-XXNPMF-16Sxx (standard, non-flex)
2090-CPxM4DF-16AFxx (continuous-flex)
2090-XXNFMF-Sxx (standard, non-flex)
2090-CFBM4DF-CDAFxx (continuous-flex)
Absolute High-resolution Feedback
MPAR-A/B3xxxE
MPAR-A/B3xxxH
2090-CPxM7DF-16AAxx (standard, non-flex)
2090-CPxM7DF-16AFxx (continuous-flex)
2090-CFBM7DF-CEAAxx or
2090-CFBM7DD-CEAAxx (standard, non-flex)
2090-CFBM7DF-CEAFxx or
2090-CFBM7DD-CEAFxx (continuous-flex)
Absolute High-resolution Feedback
