Rockwell Automation Publication GMC-RM008A-EN-P - September 2011 3
Ultra3000 Drive Systems
Determine What You Need
For each Ultra3000 drive system, you need to know the drive and motor/actuator catalog numbers to determine the motor
power and feedback cable catalog numbers. Interface cables and connector kits are also required. Optional equipment
includes Bulletin 2090 AC line filter, shunt resistor, and others. Example diagrams of the required equipment listed on this
page are shown on
page 4 .
Ultra3000 Drive Modules
Ultra3000 Servo Drive Communication Interface
Refer to the Kinetix Servo Drives Specifications Technical Data, publication GMC-TD003 , for detailed descriptions and
additional specifications for the Ultra3000 drive family.
Ultra3000 Drives
Cat. No.
Input Voltage
Output Power
(continuous) Output Current
(continuous)
Features
2098-DSD-005x-xx
200V Class
0.5 kW 1.8 A, rms • Requires an external 12…24V power supply for
proper operation of the digital I/O.
• Requires an external +5V power supply to maintain
logic power when the AC line voltage is removed. (1)
(1) Use external 24V I/O power supply to feed drive-mounted breakout boards (catalog numbers 2090-U3CBB-DM12 and 2090-U3CBB-DM44) with 24…5V DC converter.
2098-DSD-010x-xx 1.0 kW 3.5 A, rms
2098-DSD-020x-xx 2.0 kW 7.1 A, rms
2098-DSD-030x-xx 3.0 kW 10.6 A, rms
Requires an external 12…24V power supply for proper
operation of the digital I/O.
2098-DSD-075x-xx 7.5 kW 24.7 A, rms
2098-DSD-150x-xx 15 kW 45.9 A, rms
2098-DSD-HV030x-xx
400V Class
3.0 kW 5.0 A, rms
2098-DSD-HV050x-xx 5.0 kW 7.8 A, rms
2098-DSD-HV100x-xx 10 kW 16.3 A, rms
2098-DSD-HV150x-xx 15 kW 24.0 A, rms
2098-DSD-HV220x-xx 22 kW 33.2 A, rms
Drive Type Drive Cat. No. Command Interface
SERCOS interface drive
2098-DSD-xxx-SE and
2098-DSD-HVxxx-SE
Fiber-optic SERCOS module
Analog drive
2098-DSD-xxx and
2098-DSD-HVxxx
Analog command interface
Digital drive with DeviceNet interface
2098-DSD-xxx-DN and
2098-DSD-HVxxx-DN
DeviceNet communication interface
Indexing drive
2098-DSD-xxxX and
2098-DSD-HVxxxX
Standalone control
Indexing DeviceNet interface drives
2098-DSD-xxxX-DN and
2098-DSD-HVxxxX-DN
