Rockwell Automation Publication GMC-RM008A-EN-P - September 2011 11
Ultra3000 Drive Systems
Ultra3000 (200V class) Drives/MP-Series Low Inertia Motor Curves
Torque
(N•m)
Torque
(lb•in)
Speed (rpm)
2000 4000 6000 8000 0
2098-DSD-005 and MPL-A1510V
0.800
0.700
0.600
0.500
0.400
0.300
0.200
0.100
0
7.08
6.19
5.31
4.42
3.54
2.65
1.77
0.88
0
Torque
(N•m)
Torque
(lb•in)
Speed (rpm)
2000 4000 6000 8000 0
2098-DSD-005 and MPL-A1520U
1.600
1.400
1.200
1.000
0.800
0.600
0.400
0.200
0
14.1
12.4
10.6
8.85
7.08
5.31
3.54
1.77
0
Torque
(N•m)
Torque
(lb•in)
Speed (rpm)
2000 4000 6000 8000 0
2098-DSD-010 and MPL-A1530U
4.00
3.50
3.00
2.50
2.00
1.50
1.00
0.50
0
35.4
30.9
26.5
22.1
17.7
13.3
8.84
4.42
0
Torque
(N•m)
Torque
(lb•in)
Speed (rpm)
2000 4000 6000 8000 0
2098-DSD-010 and MPL-A210V
1.600
1.400
1.200
1.000
0.800
0.600
0.400
0.200
0
14.1
12.4
10.6
8.85
7.08
5.31
3.54
1.77
0
Torque
(N•m)
Torque
(lb•in)
0 0
1.0
2.0
3.0
5.0
4.0
8.85
17.7
26.5
35.4
44.2
2098-DSD-020 and MPL-A220T
Speed (rpm)
1000 2000 3000 4000 0 5000 6000
Torque
(N•m)
Torque
(lb•in)
2098-DSD-020 and MPL-A230P
0 0
2.0
4.0
6.0
35.4
53.1
70.8 8.0
88.5
Speed (rpm)
0 3000 5000 4000 1000 2000
10.0
1.77
= Intermittent operating region
= Continuous operating region
