48
• •
•
•
•
A list of recipes is displayed with the columns below:
2. Select the recipe to use, and then click Next. The Batch Creation dialog box opens:
The following table describes the options on this dialog box:
Column
Description
Identifier
The recipe name.
Procedure Description
Description of the product or process at the procedure level.
Product Code
A short label that uniquely identifies the product.
Recipe Type
What type of recipe it is: Operation, Unit Procedure, Procedure,
or All Procedures.
Procedure Abstract
A summary or outline of the procedure steps.
Last Used
Displays the date and time a recipe was last used.
Box
Description
Selected Recipe
The recipe that you selected (view only).
If you click Back twice, you will be at the recipe list where you can select a
different recipe.
Version
The version of the recipe you are using (view only).
BatchCampaign.book Page 48 Wednesday, September 19, 2007 4:58 PM
