26
• •
•
•
•
Configure RSBizWare BatchCampaign
The first time you run BatchCampaign, an Error! dialog box displays. This occurs
because a server and database have not yet been configured for BatchCampaign.
1. Click the Start button, point to All Programs > Rockwell Software >FactoryTalk
Batch Suite > BatchCampaign, and then select BatchCampaign.
2. Click OK to continue. BatchCampaign opens.
3. Click the Log In button, type a valid user name and password, and then click OK.
(See “Logging on to RSBizWare BatchCampaign” for more information.)
Configure the Database
BatchCampaign stores configuration information and buffered batches in a Microsoft
Access database (BatchCampaign.mdf) in its root folder. You do not need to install
Microsoft SQL Server if you use this database. If SQL Server is part of your FactoryTalk
Batch solution you can configure BatchCampaign to store its configuration information
and buffered batches in a SQL database. You must specify the SQL Server and the name
of the database prior to any other configuration or configure BatchCampaign to use the
Access database.
BatchCampaign.book Page 26 Wednesday, September 19, 2007 4:58 PM
