Page 69
Rockwell Automation Publication 7000-IN012B-EN-P - June 2014
69
Commissioning the Drive Chapter 4
SPS Board LEDs
There is one green LED on each of the SPS boards labeled DS1. If the SPS board
is healthy, the corresponding LED will be illuminated (need 1, 2 or 3 test power
harnesses for 2kV/3...4 kV/6 kV drives, respectively). If any of the SPS board DS1
LEDs do not illuminate, the SPS board is defective. The output voltage should be
within 20 V, ± 2%.
Gating Tests
After testing the drive converters without Medium Voltage and verifying the
power supply output values, test the SCRs and SGCTs under low voltage control
power.
The following procedures describe the next level of device testing:
• Gating Test Mode
• SCR Firing Test
• SGCT Firing Test
Test Points (SPS)
Expected Value
Measured Value
U1a
J2 1-2
+20V DC
U1b
J2 1-2
+20V DC
U1c
J2 1-2
+20V DC
U4a
J2 1-2
+20V DC
U4b
J2 1-2
+20V DC
U4c
J2 1-2
+20V DC
U3a
J2 1-2
+20V DC
U3b
J2 1-2
+20V DC
U3c
J2 1-2
+20V DC
U6a
J2 1-2
+20V DC
U6b
J2 1-2
+20V DC
U6c
J2 1-2
+20V DC
U5a
J2 1-2
+20V DC
U5b
J2 1-2
+20V DC
U5c
J2 1-2
+20V DC
U2a
J2 1-2
+20V DC
U2b
J2 1-2
+20V DC
U2c
J2 1-2
+20V DC
