Rockwell Automation Publication 6181X-UM001B-EN-P - May 2011 13
Chapter
2
Installation
Chapter Objectives This chapter provides pre-installation information and procedures to mount the
computer and make connections:
• European Union compliance
• Environment and enclosure information
• Installation considerations
• Mounting clearances
• Product dimensions
• Mounting the display computer
• Mounting the non-display computer
• Connecting peripherals
• Applying power
• Functional ground screw
• Connecting to a network
European Union Directive
Compliance This product meets the European Union Directive requirements when installed
within the European Union or EEA regions and have the CE mark. A copy of the
Declaration of Conformity is available at the Rockwell Automation website
http://www.ab.com under Product Certification.
To comply with EN 55022 and EN 55024, use the following shielded or
unshielded cable as specified in this table.
ATTENTION: To comply with EN 55022 and EN 55024, all I/O cables must
be less than 30 m (98.42 ft). These cables must not exit the building at any
point and shall not directly connect to cables outside the building.
Table 1 - Shielded or Unshielded Cable
Cable Type Required Attribute
LAN Shielded or Unshielded
USB Shielded
Serial RS-232 Shielded
DVI Shielded
VGA Shielded
DC Power Unshielded
