Installing rslinx, Installing rslinx -13 – Rockwell Automation 9303 DRIVE TOOLS32 GETTING STARTED User Manual
Page 27

Overview
1-13
Publication 9303-5.13 – March 1998
11. Review your setup information.
Depending on the files transferred to your PC during installation, the
following window may appear.
12. Click OK. Your system will restart.
Installing RSLinx
After you install DriveTools32, the RSLinx InstallShield wizard program
appears automatically. You must have RSLinx installed and properly configured
before you can use DriveTools32.
Important: If you already have RSLinx (version 1.7) installed on your PC, do
not install RSLinx Lite. Click Cancel and then Exit Setup.
Important: If the RSLinx InstallShield wizard does not appear automatically,
you can start it in Windows Explorer. Start Windows Explorer, click your
CD-ROM drive, DriveTools32, RSLinx, V1.7, Disk1, and then setup.exe.
If you want to:
Click:
Begin copying the files
Next.
Change information
Back. You can continue using the Back button until you reach the
information that you wish to change.
Exit the setup script
Cancel
