Overview
1-5
Publication 9303-5.13 – March 1998
Using DriveTools32 with a 1395 Drive
If you plan to use DriveTools32 with a 1395 drive, you have the following
options:
To use this
communication type:
You need this
hardware
on the drive-side:
And this hardware
on the PC-side:
For installation,
refer to:
RS-232 Point-to-Point
Serial
1300-ITSSC
RS232 port
RS-232 Serial to DH+
Direct
Multi-Communications
Adapter Board
(1395-KP51)
RS232 port and
1770-KF2
DH+ Direct
Multi-Communications
Adapter Board
(1395-KP51)
1784 -KTx, -KL, or
-PCMK
DH+ to RIO Block
Transfer Pass Thru
Node Adapter
(1395-KP50) or
Multi-Communications
Adapter (1395-KP51)
1784-KTx, -KL, or
-PCMK
Ethernet to RIO Block
Transfer Pass Thru
Node Adapter
(1395-KP50) or
Multi-Communications
Adapter (1395-KP51)
Ethernet Interface
Running TCP/IP
RSLinx Gateway
Server: Ethernet to
DH+ Direct
Multi-Communications
Adapter (1395-KP51)
Client: Ethernet
Interface Running
TCP/IP
Server: Ethernet
Interface Running
TCP/IP and 1784-KTx,
-KL, or -PCMK
RSLinx Gateway
Server: Ethernet to
DH+ to RIO Block
Transfer Pass Thru
Node Adapter
(1395-KP50) or
Multi-Communications
Adapter (1395-KP51)
Client: Ethernet
Interface Running
TCP/IP
Server: Ethernet
Interface Running
TCP/IP and 1784-KTx,
-KL, or -PCMK
