Overview
1-3
Publication 9303-5.13 – March 1998
Using DriveTools32 with an Allen-Bradley SCANport-Compatible Product
You can use DriveTools32 with a number of Allen-Bradley SCANport-
compatible products, including a 1305 Micro, 1336E (IMPACT), 1336F (PLUS
II), 1336G (Fibers), 1336S (PLUS), 1336T (FORCE), 1557 (Med. Volt), 1394
Servo, or SMC drive. For a list of Allen-Bradley SCANport-compatible
products, refer to Appendix A. If you use DriveTools32 with one of these
products, you have the following options:
To use this
communication type:
You need this
hardware
on the drive-side:
And this hardware
on the PC-side:
For installation,
refer to:
RS-232 Point-to-Point
Serial
1203-GD2 or
1203-GK2 and
appropriate cable,
or 1336-GM2
RS232 port
DH+ to RIO Block
Transfer Pass Thru
1203-GD1 or
1203-GK1 and
appropriate cable,
or 1336-GM1
1784-KTx, -KL, -PCMK
Ethernet to RIO Block
Transfer Pass Thru
1203-GD1 or
1203-GK1 and
appropriate cable,
or 1336-GM1
Ethernet Interface
Running TCP/IP
RSLinx Gateway
Server DH+ to RIO
Block Transfer Pass
Thru
1203-GD1 or
1203-GK1 and
appropriate cable,
or 1336-GM1
Client: Ethernet
Interface Running
TCP/IP
Server: Ethernet
Interface Running
TCP/IP and 1784-KTx,
-KL, or -PCMK
