1-4
Overview
Publication 9303-5.13 – March 1998
Using DriveTools32 with a 1336T (FORCE) Drive
The 1336T (FORCE) drive is a SCANport-compatible product that can use all
options listed above. In addition, it offers the following options:
To use
this communication
type:
You need this
hardware
on the drive-side:
And this hardware
on the PC-side:
For installation,
refer to:
RS-232 Serial to DH+
Direct
PLC Communications
Adapter Board
(1336T-GT1EN)
RS232 port and
1770-KF2
DH+ Direct
PLC Communications
Adapter Board
(1336T-GT1EN)
1784 -KTx, -KL, -
PCMK
DH+ to RIO Block
Transfer Pass Thru
PLC Communications
Adapter Board
(1336T-GT1EN)
1784-KTx, -KL, -PCMK
ControlNet Direct
ControlNet Adapter
Board (1336T-GT3EN),
ControlNet Repeater
Adapter (1786-RPA),
and ControlNet Fiber
Module (1786-RPFM)
KTC, KTC(X)
Ethernet to RIO Block
Transfer Pass Thru
PLC Communications
Board (1336T-GT1EN)
Ethernet Interface
Running TCP/IP
RSLinx Gateway
Server: Ethernet to
DH+ Direct
PLC Communications
Adapter Board
(1336T-GT1EN)
Client: Ethernet
Interface Running
TCP/IP
Server: Ethernet
Interface Running
TCP/IP and 1784-KTx,
-KL, or -PCMK
RSLinx Gateway
Server: Ethernet to
DH+ to RIO Block
Transfer Pass Thru
PLC Communications
Adapter Board
(1336T-GT1EN)
Client: Ethernet
Interface Running
TCP/IP
Server: Ethernet
Interface Running
TCP/IP and 1784-KTx,
-KL, or -PCMK
