Appendix
B
7000 “A” Frame
7000A-UM151D-EN-P – March 2013
Catalog Number Explanation
for PowerFlex 7000 Variable Frequency Drives
First Position
Second Position
Third Position
Fourth Position
Fifth Position
Sixth Position
Seventh Position
7000
– A
40
D
A
– RPDTD
– 1 - … etc.
Bulletin
Number
Service Duty/
Altitude Code
Current
Rating
Enclosure
Type
Line and
Control
Voltages
Rectifier
Configuration/
Line Impedance
Type
Options
(Refer to
PowerFlex 7000
Medium Voltage Drives
Global Price List)
Code
Description
A
Normal Duty, 0-1000 m Altitude
Maximum 40°C Ambient
B
Normal Duty, 1001-5000 m Altitude
Reduced Ambient (from 40°C offering)
1001 – 2000 m = 37.5°C
2001 – 3000 m = 35°C
3001 – 4000 m = 32.5°C
4001 – 5000 m = 30°C
C
Heavy Duty, 0-1000 m Altitude
Maximum 40°C Ambient
D
Heavy Duty, 0-5000 m Altitude
Reduced Ambient (from 40°C offering)
– Same as ‘B’ above
E
Normal Duty, 0-1000 m Altitude
Maximum 35°C Ambient
F
Normal Duty, 1001-5000 m Altitude
Reduced Ambient (from 35°C offering)
1001 – 2000 m = 32.5°C
2001 – 3000 m = 30°C
3001 – 4000 m = 27.5°C
4001 – 5000 m = 25°C
G
Heavy Duty, 0-1000 m Altitude
Maximum 35°C Ambient
J
Normal Duty, 0-1000 m Altitude
Maximum 50°C Ambient
L
Heavy Duty, 0-1000 m Altitude
Maximum 50°C Ambient
N
Normal Duty, 0-1000 m Altitude
Maximum 20°C Ambient
Z
Custom Configuration
(Contact Factory)
Code
Description
7000A
“A” Frame (Air Cooled)
7000
“B” Frame (Air Cooled)
7000L
“C” Frame (Liquid Cooled)
Code
Description
D
Type 1 w/gasket (IP21)
T
Type 1 w/gasket (IP21)
– Seismic rated
K
Type 12 w/vents and
filters (IP42)
U
Type 12 w/vents and
filters (IP42) – Seismic
rated
Code
Description
RPDTD
AFE Rectifier with Integral Line
Reactor and Direct-to-Drive DC
Link
RPTX
AFE Rectifier with provision for
connection to separate Isolation
Transformer (standard DC Link)
RPTXI
AFE Rectifier with integral Isolation
Transformer (standard DC Link)
RPLR
AFE Rectifier with Integral Line
Reactor and Standard DC Link
(No longer offered for sale)
R6TX
6-pulse Rectifier with provision for
connection to separate Isolation
transformer (standard DC Link)
(No longer offered for sale)
R18TX
18-pulse Rectifier with provision for
connection to separate Isolation
Transformer (standard DC Link)
See Table B-1
Code
Description
40
40 Amp
46
46 Amp
53
53 Amp
61
61 Amp
70
70 Amp
81
81 Amp
93
93 Amp
105
105 Amp
120
120 Amp
140
140 Amp
160
160 Amp
185
185 Amp
215
215 Amp
250
250 Amp
285
285 Amp
325
325 Amp
375
375 Amp
430
430 Amp
495
495 Amp
575
575 Amp
625
625 Amp
657
657 Amp
720
720 Amp
Not all amperages are
available at all ambient/
altitude configurations.
Refer to Price Lists for
exact offering.
