Error Codes
Appendix B
BĆ7
Error Code
(decimal):
Description: Error Code
(Hex):
213 D5 Program end before delimiter rung.
214 D6 ~XIC in update mode.
215 D7 No memory access yet.
216 D8 Own link ADDR expected in update cmd.
217 D9 No symbolic addressing yet.
218 DA Fault bits in non-dt regions.
219 DB Startbit not 10 to 17.
220 DC ~(XIC) in command rung.
221 DD ~GET (for remote address).
222 DE ~GET (for start address).
223 DF ~GET (for end address).
224 E0 Start ADDR is greater than end ADDR.
225 E1 No (XIC or XIO) in bitwrite command.
226 E2 Number of addresses is greater than MAXSCATTERED.
227 E3 Node is less that 1 or greater than 254
228 E4 Errata after a valid command.
229 E5 Same start bit used twice.
230 E6 Too much time-critical data to send.
240 E7 Too big for low priority.
250 E8 User dropped SB before we were done.
251 E9 Tried to use reserve code.
252 EA Link specified in a time-critical command.
253 EB User ID must be 0 to 15 (010 - 027)
254 EC Invalid node number.
