Publication 1746-UM005B-EN-P - June 2004
Chapter
4
Module Operation and System Considerations
This chapter describes:
•
Interface between the Module and Processor
•
System Considerations
Interface between the
Module and the Processor
This section describes how to set up an analog module in a SLC 500
system.
Entering Module ID Codes
When configuring an analog module for an SLC 500 system using your
programming software, a list of the different I/O modules, including
the analog modules, is most likely provided for you. If a list is not
provided, you need to enter the module identification code when
configuring the slot. Refer to the table below for the appropriate
analog module ID code.
Using the Hand-Held Terminal (HHT) firmware v1.1, enter the proper
MODULE ID CODE under the “other” selection. Version 2.0 or later of
the HHT firmware provides a list of I/O modules. Refer to the
following publications for complete information:
•
your programming software’s user manual
•
the Hand-Held Terminal User Manual
Catalog No.
Module ID Code
1746-NI4
4401
1746-NIO4I
3201
1746-NIO4V
3202
1746-NO4I
5401
1746-NO4V
5402
