Publication 1746-UM005B-EN-P - June 2004

1-2 Overview

1746-NI4 Analog Input Module

The 1746-NI4 Analog Input module contains 4 analog input channels
that are user selectable per channel for voltage or current to support a
variety of monitoring and controlling applications

1746-NIO4I and NIO4V Analog Combination Modules

The NIO4I and NIO4V Analog Combination I/O modules provide two
input and two output channels in a single slot module. The
1746-NIO4I module contains two current or voltage inputs (user
selectable per channel), and two current outputs. The 176-NIO4V
module contains two current or voltage inputs (user selectable per
channel) and two voltage outputs.

1746-NO4I and NO4V Analog Output Modules

The NO4I and NO4V Analog Output Modules provide 4 analog output
channels. The NO4I module contains four current outputs. The NO4V
module contains four voltage outputs. Both of these modules support
a variety of monitoring and controlling applications.

For more specification information, refer to Appendix A.

Catalog 1746-

Input Channels per
Module

Output Channels per
Module

Backplane Current Draw

External 24V dc Power
Supply Tolerances

5V (max.)

24V (max.)

NI4

4 differential, voltage or
current selectable per
channel, not individually
isolated

NA

35 mA

85 mA

NA

NIO4I

2 differential, voltage or
current selectable per
channel, not individually
isolated

2 current outputs, not
individually isolated

55 mA

145 mA

NA

NIO4V

2 differential, voltage or
current selectable per
channel, not individually
isolated

2 voltage outputs, not
individually isolated

55 mA

115 mA

NA

NO4I

NA

4 current outputs, not
individually isolated

55 mA

195 mA

24 ±10% at 195 mA max.

(21.6 to 26.4V dc)

(1)

NO4V

NA

4 voltage outputs, not
individually isolated

55 mA

145 mA

24 ±10% at 145 mA max.

(21.6 to 26.4V dc)

(1)

(1) Required for some applications if SLC 24V power is not readily available.
