Chapter 5
5Ć3
Table 5.B
Example of Editing a Message Procedure Through an Industrial Terminal
System Prompt Action Key Strokes
Create the message procedure. In this
case, MH1 mean Data Highway message
procedure number 1.
ME, MH1, [ENT]
Deleting existing null characters. [DEL] [DEL] [DEL] [DEL]
Enter message procedure commands.
Note that you must use either an EXIT or a
STOP command to end each procedure.
(other commands)
#H022$B0:5CC:1 [ENT]
$B0:6=CC:1*2 [ENT]
EXIT [ENT]
[CANCEL CMD]
Insert the symbol definition for the name of
the message procedure.
IS [ENT]
ENTER SYMBOL
STRING
Enter the name of the message procedure.
In this case, the name is PROC_1.
PROC_1 [ENT]
ENTER SYSTEM
ADDRESS OR
SYMBOL
Enter the address where the message
procedure is stored. In this case, the
symbolic address MH1 can be used.
MH1 [ENT]
ENTER SYMBOL TYPE Enter the symbol type for the message
procedure name. This is always 2 for the
1775-KA module.
2 [ENT]
Table 5.C
Example of Editing a Message Procedure Through a Data Terminal
S4B> Enter the edit mode and create the
message procedure name. Note that the
1775-S4B module automatically creates
the symbol definition for the message
procedure name.
EDIT /H@PROC_1 [RET]
*
*
Enter the insert mode of editing I [RET]
Enter the message procedure command.
Note that you must use either EXIT or
STOP command to end each procedure.
(other commands)
#H022$B0:5=CC:1 [RET]
$B0:6=CC:1*2 [RET]
EXIT [RET]
Exit from the insert mode of editing. [RET]
Exit from the editing mode of the
1775-S4B module.
E [RET]
S4B>
