Introduction
Chapter 1
1Ć2
Chapter 10 – describes how to write a full–duplex line driver to enable
a computer to communicate to the 1775–KA’s RS–232–C channel.
Chapter 11 – describes how to write a half duplex line driver to enable
a computer to communicate to the 1775–KA’s RS–232–C channel.
Chapter 12 – describes the network and application layers of a software
driver to enable a computer to communicate to the 1775–KA’s
RS–232–C channel.
Appendix A – shows detailed message formats.
Appendix B – lists error codes reported by the 1775–KA, 1771–KA,
1771–KG, 1771– KE/KF, 1773–KA, and 1774–KA modules.
Appendix C – lists diagnostic counters stored at the 1775–KA,
1771–KA, 1771–KG, 1771–KE/KF, 1773–KA and 1774–KA modules.
Appendix D – gives detailed flow charts of an example of software
logic for implementing a full–duplex protocol.
Related Documentation
Read this manual in conjunction with the documentation listed in
Table 1.A and Table 1.B. Table 1.A lists related PLC–3 documentation
and Table 1.B lists related Data Highway documentation.
Table 1.A
Related PLC-3 Documentation
Publication
Number
(Old/New No.)
Title
1775-800/1775-6.7.1
PLC-3 Installation and Operations Manual
1775-801/1775-6.4.1
PLC-3 Programming Manual
1775-806/1775-6.5.3
I/O Scanner-Message Handling Module User's
Manual
1775-900/1775-2.1
PLC-3 Controller Data Sheet
1775-901/1775-2.2
PLC-3 Main Processor Module Data Sheet
1775-902/--------
PLC-3 Memory Organization Data Sheet
1775-904/1775-2.4
Power Supply Data Sheet
1775-908/1775-2.6
PLC-3 Memory Modules Data Sheet
1775-910/1775-2.8
PLC-3 Main Chassis Data Sheet
