Rockwell Automation Publication 1747-UM076C-EN-E - January 2013 59
Appendix
B
Adapter Web Dialogs
Overview The Web dialog of the I/O adapter offers extensive internal and network
diagnostics. To view the Web dialogs, enter the IP address of the I/O adapters
into your browser.
Work with the Home Page Use the adapter diagnostics home page to access other adapter diagnostics web
pages and see the following information.
• Host Name
• Module Description
• Module Location
• IP Address
• Ethernet Address (MAC)
• DHCP Enabled
• Product Revision
• Serial Number
• Status
• Auto Negotiate
• Media Speed
• Half or Full Duplex
Topic Page
Work with the Home Page 59
Work with the Diagnostics Pages 61
Use the Diagnostic Overview Page 61
Use the Network Settings Page 63
Use the Ethernet Statistics Page 64
Use the I/O Connections Page 65
Work with the Configuration Pages 66
Use the Device Identity Page 68
Use the Network Configuration Page 68
Use the Device Services Page 70
