Rockwell Automation Publication 1747-UM076C-EN-E - January 2013 21
Chapter
4
Plan to Use Your EtherNet/IP Adapter
This chapter explains how the adapter operates on Ethernet and provides
information to assist you in configuring your system. This includes
information on:
• compatible 1746 and 1747 modules
• overview of adapter operation
• software requirements
• module connections
• module keying
• output operation during Fault and Idle modes
Compatible 1746 and
1747 I/O Modules The majority of 1746 and 1747 discrete, analog and specialty modules are
compatible with the 1747-AENTR adapter.
The following tables provide lists of supported and unsupported modules.
List of I/O Modules Supported by the 1747-AENTR Adapter
Catalog
Number Type Catalog
Number Type
1746-IA4 AC Digital Input Module 1746-OG16 DC Digital Output Module
1746-IA8 AC Digital Input Module 1746-OV8 DC Digital Output Module
1746-IA16 AC Digital Input Module 1746-OV16 DC Digital Output Module
1746-IB8 DC Digital Input Module 1746-OV32 DC Output Module
1746-IB16 DC Digital Input Module 1746-OVP16 DC Digital Output Module
1746-IB32 DC Input Module 1746-OW4 AC/DC Relay Output Module
1746-IC16 DC Digital Input Module 1746-OW8 AC/DC Relay Output Module
1746-IG16 DC Digital Input Module 1746-OW16 AC/DC Relay Output Module
1746-IH16 DC Digital Input Module 1746-OX8 AC/DC Relay Output Module
1746-IM4 AC Digital Input Module 1746-FIO4I Analog Combination Module
1746-IM8 AC Digital Input Module 1746-FIO4V Analog Combination Module
1746-IM16 AC Digital Input Module 1746-INT4 Thermocouple Isolated Input
Module
1746-IN16 AC/DC Digital Input Module 1746-NI4 Analog Input Module
1746-IO4 Digital Combination Module 1746-NI8 (1) Analog Input Module
1746-IO8 Digital Combination Module 1746-NIO4I Analog Combination Module
1746-IO12 Digital Combination Module 1746-NIO4V Analog Combination Module
