3-8 Install and Use the 1784-PCC Card in Windows 2000/XP
Publication 1784-IN034D-EN-P - June 2002
9. Run the 1784-PCC test utility as described in Chapter 6 to verify the
installation. If the test utility fails, refer to Troubleshoot the Card Installation
on page 3-13.
1784-PCC Hardware Properties
Windows 2000/XP provides properties dialog boxes for removable devices. The
properties dialog boxes provide the following:
• general information such as device status, manufacturer and card location
• device driver information such as driver version and buttons for you to
uninstall and update the driver
• resource information such as interrupt request settings and memory range
settings
We recommend you verify that the card is running properly after you install the
1784-PCC card and the driver. Refer to Troubleshoot the Card Installation on
page 3-13.
Stop and Eject the 1784-PCC Card
Before you remove the PCC card from its slot, you need to stop the communication
to the card. To stop the card:
1. Double-click on the Unplug/eject Hardware icon on your taskbar.
.
TIP
If you don’t have the icon on your taskbar, refer to Show
the Card Unplug/Eject Icon on the Taskbar on page 3-28.
