Care of your mass storage system appendix a – Rockwell Automation 1770-M12 Mass Storage Systems User Manual
Page 47

Care of Your Mass Storage System
Appendix A
AĆ7
Figure 1.22
How to Insert a MicroĆfloppy into a Mass Storage System
Mass Storage System
Back View
Select
Position 1
When the microĆfloppy seats
properly into the access slot
this
indicator lights
green.
Label faces up
Indicator lights green
11979
POWER
120V AC 50 60Hz
5A 250V FUSE
J19
4.
Select position 1 of the POWER switch. If power is on, the POWER
indicator lights green. If power is not on, then refer to chapter 5 for
troubleshooting aids.
5.
Hold the micro-floppy with the labels facing up and the read/write access
slot nearest the drive.
ATTENTION: Do not insert the micro-floppy with its labels facing
down. Damage to the micro-floppy and loss of data can occur.
