Hardware Features of the Mass Storage
Systems
Chapter 2
2Ć9
P/N 966289–01
Connects to: PARALLEL CHANNEL OUT J20
If you would like to make your own cables, appendix C contains the cable pin
assignments. Here are the 3M Company part numbers for the connector cables.
You will need two connectors for each cable:
3M Company Part Number
Mass Storage System
3564-1002 or equivalent
1770-M10
3636-100 or equivalent
1770-M12
The 1770–M11 system comes with a micro–floppy diskette, labeled:
Operating System for PLC–3 Peripheral Communication Module/Mass
Storage Systems. It contains the software to be executed by the DMIM.
In this chapter you read about:
hardware feature of the mass storage systems
cables required for the mass storage systems
In the next chapter, we describe how to install and connect your mass storage
system to each compatible Allen–Bradley product.
Program Diskette
Chapter Summary
