Care of Your Mass Storage System
Appendix A
AĆ6
protected from erasing, deleting, or accidental overwriting file information.
When close (red shows), you can write (record data) onto the micro-floppy.
Figure 1.21 shows the back view hardware.
Figure 1.21
Back View of the MicroĆfloppy
ЙЙЙЙЙЙ
ЙЙЙЙЙЙ
ЙЙЙЙЙЙ
ЙЙЙЙЙЙ
ЙЙЙЙЙЙ
ЙЙЙ
ЙЙЙ
ЙЙЙ
ЙЙЙ
11978
Protect
Access
Notch
Spindle
Hole
Read/Write Access Slot
Do not touch the
recording surfaces
Spindle Hole
This is where the micro-floppy internally connects to the disk drive.
Read/Write Access Slot
This slot moves back and forth when the micro-floppy is placed into the disk
drive. This slot exposes the actual recording surface. Do not slide the access
door and touch the recording surface.
To insert a micro-floppy into a mass storage system, follow these steps
(Figure 1.22):
Back View Hardware Features
How to Insert Your
MicroĆFloppy
