Rockwell Automation 1770-M12 Mass Storage Systems User Manual
Page 32

System Start-Up
Chapter 4
4Ć3
14.
Insert a 220V AC power cord into J19.
E
FUSE
PULL
Power cord location
If you are unfamiliar with micro-floppies, read appendix A before proceeding.
After you’ve connected your mass storage system, you’ve ready to begin
operations. make sure the POWER switch is at position 0. Perform the
following steps for your 1770-M10 system (Figure 1.16):
Figure 1.16
System StartĆup Procedure for the 1770ĆM10 System
1770-M10 Mass Storage System - Back View
Select position 1
Insert power cord
MASS STORAGE SYSTEM
Indicator lights green
M10
11972
1.
Insert the connector end of the power cord into J19.
2.
Insert the plug into the power outlet.
System StartĆup Procedure for
the 1770ĆM10 System
