C-8 Configuration Using the 1769-IF4XOF2 Combination Analog Module with a CompactLogix System
You can only modify the configuration file to enable the input and
output channels being used.
Once the configuration is complete for the 1769-IF4XOF2 module,
and any other modules in your system have been entered and
configured, you can write your program, and save and download
your project to the controller. The configuration files are downloaded
to the controller at the same time the project is downloaded to the
controller. They are also sent to the module at power up and when an
inhibited module is uninhibited.
To enable channels:
Using RSLogix 5000 version 8
Generic Profile Using RSLogix 5000 version 10
Thin Profile
Enter a 1 in bits Local:1:C.Data[0]/4 though
Local:1:C.Data[0]/7 for input channels 0
through 3. Set Local:1:C.Ch0InputEn through
Local:1:C.Ch3InputEn equal to 1.
Enter a 1 in bits Local:1:C.Data[1]/4 and
Local:1:C.Data[0]/5 for input channels 0 and
1. Set Local:1:C.Ch0OutputEn through
Local:1:C.Ch3OutputEn equal to 1.
TIP
All other selections in the 6 word configuration file
for the analog combination module concern HLS and
UDSS, which is not yet supported by the
CompactLogix controllers. Leave these settings at
their default values.
