4–7 Configuring Your Module
Description Bits Word
Words 35
thru 39
These words are a repeat of words 25 through 29 with the exception
of the output number. These words are for output 2.
Words 40
thru 44
These words are a repeat of words 25 through 29 with the exception
of the output number. These words are for output 3.
Words 45
thru 49
These words are a repeat of words 25 through 29 with the exception
of the output number. These words are for output 4.
Words 50
thru 54
These words are a repeat of words 25 through 29 with the exception
of the output number. These words are for output 5.
Words 55
thru 59
These words are a repeat of words 25 through 29 with the exception
of the output number. These words are for output 6.
Words 60
thru 64
These words are a repeat of words 25 through 29 with the exception
of the output number. These words are for output 7.
In this chapter you learned how to configure your module’s
hardware, condition your inputs and enter your data.
Chapter Summary
