Appendix B – Serial Communications
B-8
Table B.4 Parameter Grouping/User Settings (cont.)
Group Parameter Name Param
eter #
Disolay
Units
Drive Units
Scale Factor ➁
Min Max Factory Setting User’s
Setting
Freq Select 1 5 Text ➀ 1 –– –– Adapter 1
Freq Select 2 6 Text ➀ 1 –– ––– Remote Pot
Jog Frequency 24 Hz 100 0 400.0 10.0
Prst/2nd Accel 26 Text ➀ 1 –– –– Preset
Upper Presets 72 Text ➀ 1 –– –– Disabled
Accel Time 2 30 Seconds 10 0.0 3600.0 10.0
Decel Time 2 31 Seconds 10 0.0 3600.0 10.0
S
et Preset Freq 1 ➂ 27 Hz 100 0.0 400.0 0.0
y
S
Preset Freq 2 ➂ 28 Hz 100 0.0 400.0 0.0
enc Preset Freq 3 ➂ 29 Hz 100 0.0 400.0 0.0
equ
e
Preset Freq 4 ➂ 73 Hz 100 0.0 400.0 0.0
Freq Preset Freq 5 ➂ 74 Hz 100 0.0 400.0 0.0 F
Preset Freq 6 ➂ 75 Hz 100 0.0 400.0 0.0
Preset Freq 7 ➂ 76 Hz 100 0.0 400.0 0.0
Skip Freq 1 32 Hz 1 0 400 400
Skip Freq 2 33 Hz 1 0 400 400
Skip Freq 3 34 Hz 1 0 400 400
Skip Freq Band 35 Hz 1 0 15 0
MOP Increment 22 Hz/Second 1 0.00 255.00 0.00
➀ Refer to Table B.5 on pages B-13, B-14 and B-15 for the numerical equivalent of the text descriptions.
➁ Refer to page B-2.
➂ Not accessible with data links [Data In A1] through [Data Out D2].
