Appendix A – Block Diagram and Specifications
A-2
Table A.1 Specifications
Drive Bulletin 1305 Drive Rated 200-230 V AC Bulletin 1305 Drives Rated 380-460 V AC r e
-AA02A -AA03A -AA04A -AA08A -AA12A -BA01A -BA02A -BA03A -BA04A -BA06A -BA09A
OUTPUT RATINGS
3 Phase Motor Rating
kW (HP) 0.37
(1/2)
0.55
(3/4)
0.75
(1)
1.5
(2)
2.2
(3)
0.37
(1/2)
0.55
(3/4)
0.75
(1)
1.5
(2)
2.2
(3)
4.0
(5)
Output Current (A) ➀ 2.3 3.0 4.5 8.0 12.0 ➁ 1.3 1.6 2.3 4.0 6.0 ➂ 9.0 ➃
Output Voltage Adjustable from 0 V to Input Voltage
Output Frequency (Hz) 0 to 400Hz Programmable
INPUT RATINGS
Input Voltage &
Frequency 200/230V Three Phase, 50/60 Hz 380/460V Three Phase, 50/60 Hz
Operational Range (V) 180-265V, 47-63 Hz 340V-500V, 47-63 Hz
Input kVA 0.9 1.3 1.7 3.1 4.6 0.9 1.3 1.7 3.1 4.6 7.0
Power Factor
(Displacement) 0.8 (Lagging)
Efficiency (%) 97.5 % (Typical)
Power Dissipation (W) 27 34 46 76 108 21 27 34 52 73 107
➀ If the [PWM Frequency] is set above 4kHz, the output current rating must be derated per the chart on page 5-18.
➁ Output current value listed for 200V input voltage. At 230V input voltage, output current is 9.6A for 3 phase.
➂ Output current value listed for 380V input voltage. At 415V input voltage, output current is 5.3A. At 460V input voltage, output current is 4.8A.
➃ Output current value listed for 380V input voltage. At 415V input voltage, output current is 8.4A. At 460V input voltage, output current is 7.6A.
