SCANport Messaging B–21
Publication 1203–5.9 –– October 1996
Read Product Series Number
The Read Product Series Number message lets you request the
product series number from a SCANport device. The following is an
example of this request:
Service=Get Attribute Single
Internal A–B Vendor Specific Class
Instance
Attribute
Data Length=0 Bytes
M0:e.000
M0:e.001
M0:e.002
M0:e.003
M0:e.004
000e
0092
0000
0003
0000
Value
Read Product Series Number
Service=Get Attribute Single
Internal A–B Vendor Specific Class
Instance
Attribute
Data Length=6 Bytes
M1:e.100
M1:e.101
M1:e.102
M1:e.103
M1:e.104
000e
0092
0000
0003
0006
Value
Response
Product Series Number (Value 1=A, 2=B, ...)
Discard
Discard
M1:e.105
M1:e.106
M1:e.107
0001
0000
0000
Figure B.15 shows a Read Product Series Number request. The
product series is A (1=A, 2=B, and so forth).
Figure B.15
Example of Read Product Series Number
address 0 1 2 3 4 5 6 7 8 9
N10:0 000e 0092 0000 0003 0000
address 0 1 2 3 4 5 6 7 8 9
N11:0 000e 0092 0000 0003 0006 0001 0000 0000
