I/O Definition
Appendix B
Block Transfer and Discrete
B–5
Table B.4
Acknowledge Factory Configuration Parameters
Parameter
Number
Word
Number
Description
Range
Modulus
1
1
Voltage Mode
See Response Code
–––
2
2
PT Primary Rating
See Response Code
–––
3
3
Line CT Primary Rating
See Response Code
–––
4
4
Neutral CT Primary Rating
See Response Code
–––
5
5
Synchronization Method
See Response Code
–––
6
6
Voltage Match Error Upper
Acceptance Limit
See Response Code
–––
7
7
Voltage Match Error Lower
Acceptance Limit
See Response Code
–––
8
8
Frequency Match Error Upper
Acceptance Limit
See Response Code
–––
9
9
Frequency Match Error Lower
Acceptance Limit
See Response Code
–––
10
10
Phase Match Error Upper
Acceptance Limit
See Response Code
–––
11
11
Phase Match Error Lower
Acceptance Limit
See Response Code
–––
12
12
Acceptance Window Delays
See Response Code
–––
13
13
Reserved for Product Expansion
–––
–––
14
14
Maximum Alternator Output
Power
See Response Code
–––
15
15
Load Share Full–Scale Voltage
See Response Code
–––
16
16
Load Share Excess
See Response Code
–––
17
17
Load Share Deficit
See Response Code
–––
18
18
Overall Configuration Status
See Response Code
–––
19
19
Reserved for Product Expansion
–––
–––
20
20
Reserved for Product Expansion
–––
–––
21
21
Reserved for Product Expansion
–––
–––
22
22
Reserved for Product Expansion
–––
–––
23
23
Reserved for Product Expansion
–––
–––
24
24
Reserved for Product Expansion
–––
–––
25
25
Reserved for Product Expansion
–––
–––
Response Codes
Bit Status
Indication
All clear
Entry Acknowledged
Bit 0 set
Entry > Limit
Bit 1 set
Entry < Limit
Bit 2 set
Entry is Illegal Value
Bits 3 – 15
Reserved
