Chapter 3

Control Description

3-2

Table 3.B

Digital Reference Adapter Preconfigured Setup Parameters

Port A

550

551

552

553

554

555

556

557

558

559

560

561

562

563

564

565

566

567

568

569

570 - 574

575

576

577

578

579 - 582

583

584

585

586

587

588

589

590

591

592

599

Digital Ref Adapter

Preset Function

ADC Scale 1

ADC Offset 1

ADC Scale 2

ADC Offset 2

Analog PR GN 1

Analog Offset 1

Analog PR GN 2

Analog Offset 2

Digital Out 1

Digital Out 2

Digital Out 3

Digital Out 4

Digital Out 5

Digital Ref PPR

Digital Reference Scale

Digital Reference Offset

Digital Ref Filter

One/Two/Quad

Digital Multiplier Constant

Digital Multiplier Select

Not Used

DAC Scale 1

DAC Offset 1

DAC Scale 2

DAC Offset 2

Not Used

Digital In 1

Digital In 2

Digital In 3

Digital In 4

Digital In 5

Digital In 6

Digital In 7

Digital In 8

Digital In 9

Digital In 10

Adapter Board Identifier

Ext. Velocity Reference Scale

Ext. Velocity Reference Digital Offset

Trim Velocity Scale

Trim Velocity Digital Offset

External Velocity Reference Gain

Set by User

At Zero Speed

Drive Running

Drive Ready

At Current Limit

At Set Speed

Set by User

Armature Voltage Feedback Scale

Armature Voltage Feedback Offset

Armature Voltage Feedback Scale

Armature Voltage Feedback Offset

Stop

Jog 2

Start

Clear Fault

Ramp Disable

Command Enable

Jog 1

Run Reference A

Run Reference B

Run Reference C

Preset Value

1024

1750

1000

x.xx

Digital In 1 is designed for use with a normally closed (N.C.) operator device. Applying a positive control voltage

to Digital In 1 (terminal 43 of TBĆ3) will cause the bit specified to be set to zero. With no voltage applied to Digital In 1, the bit will be one.

The Digital Reference Adapter can be mounted in either Port A or Port B.

Table 3.C

and

Table 3.D

detail all parameters and their functions for both

Port A and Port B.
