3

Chapter

3-1

Control Description

Introduction

Chapter 3 contains a general description of the 1395 Digital Reference
Adapter Board. This description is intended to provide sufficient background
information to support other procedures in this manual, and to help you to
understand how to configure the board.

Parameter Overview

The Digital Reference Adapter Board contains two types of parameters,
Configurable and Set-Up. Configuration parameters control and monitor the
run-time operation of the 1395, while Set-Up parameters program the
Adapter Board functions. Programming the Set-Up parameters is
accomplished with the Programming Terminal or through another intelligent
device connected to the Drive such as an Allen-Bradley PLC. Reference the
1395 Installation Manual for an explanation of programming techniques.

All Adapter parameters are referenced by a unique 1395 system parameter
number. However, the parameter number is dependent on whether the
Adapter Board is connected to Port A or Port B of the 1395. The following
shows the parameter number ranges for Port A and Port B.

S Port A Configuration Parameters (400 – 499)
S Port A Set-Up Parameters (550 – 599)
S Port B Configuration Parameters (300 – 399)
S Port B Set-Up Parameters (500 – 549)

The Digital Reference Adapter is normally mounted in Port A of the 1395
Drive, and is shipped preconfigured and preset when it is supplied as a
standard catalog number drive. Table 3.A and

Table 3.B

detail the

pre-configured parameters.

Table 3.A

Configuration Parameters

Port A

400

401

402

403

404

405

450

451

452

453

454

Generic Function

PreĆConfigured Function
Logic Command #1

External Velocity Reference

Trim Velocity Reference

Not Linked

Not Linked

Not Linked

Logic Status

Armature Current Feedback

Armature Voltage Feedback

Not Linked

Not Linked

Fast source, Discrete input to Drive

Fast source, Analog 1 input to Drive

Fast source, Analog 2 input to Drive

Fast source, Digital Ref. input to Drive

Fast source, Digital Ref. input to Drive

Fast Source, Discrete input to Drive

Fast Sink, Discrete output from Drive

Fast sink, Analog 1 output from Drive

Fast sink, Analog 2 output from Drive

Fast sink, Digital Reference Multiplier

Fast sink, Discrete Output from Drive.
