Appendix

A

Specifications

Mechanical Ratings

Materials of Construction

Table A.A Materials of Construction

Shock and Vibration

MECHANICAL SHOCK

1. Wave Shape – 1/2 cycle sine wave

2. Duration – 11 ms

3. Frequency – 3 times in each axis

4. Maximum Allowable G Force:

Operational

100 G

Part Description

Material

Relative
Thermal

Index

Flammability

Rating

Enclosure

PBT/PC Blend Thermo plastic

248

° F

(120

° C)

94-5VA

Enclosure Gasket Nitrile 70 Durometer

Mini Connector

Shell – Nylon

Insert – PVC

Contact – Brass w/ Gold Flash Over
Palladium Nickel Plating

Gasket – Neoprene Shore ‘A’

Screws

Stainless Steel AISI 304

800E/F Operators Misc. – See Industrial Control Catalog
