4–4

Operations

Publication 800-UM001A-EN-P – June 2004

OUTPUT VALUE – Parameter 9

In normal operation, the device shall permit output to be turned on
and off. The default for the Output Value is Output Off.

Important: If the device is connected to a master with I/O

messaging, the I/O messaging will overwrite this
command.

OUTPUT FAULT ACTION – Parameter 11

In normal operation, the device shall permit configuration of the
Output Fault Action. This tells the device what to do with the output
in the case of a fault state. If Fault Value is selected, the device refers
to parameter 12, Output Fault Value, for action on a fault. The default
for Output Fault Value is Fault Value.

OUTPUT FAULT VALUE – Parameter 12

In normal operation, the device shall permit configuration of the
Output Fault Value. If parameter 11, Output Fault Action is set to
Fault Value, this parameter tells the device what to do with the output
in case of a fault state. The default for Output Fault Value is Fault
Output Off.

Value

Output Value

0

Output Off

1

Output On

Value

Fault Action

0

Fault Value

1

Hold Last State

Value

Fault Value

0

Fault Output Off

1

Fault Output On
