4–2

Operations

Publication 800-UM001A-EN-P – June 2004

Run Mode

After a successful power-up or reset, the 800E/F DeviceNet

Pendant Station enters run mode and operates as a slave device to a
master device.

Configuration is done over the network using DeviceNet

™ Manager

or RSNetWorx for DeviceNet

™ software.

ON-DELAY TIMEBASE – Parameter 4

In normal operation, the device shall permit configuration of an
on-delay timer for the input. The On-Delay timer is always enabled
for debounce on inputs. The device shall permit configuration of the
On-Delay Timebase. The default timebase is 1 ms.

ON-DELAY PRESET – Parameter 5

In normal operation, the device shall permit configuration of the
On-Delay Preset. When this value is reached, the On-Delay timer
output is set. It is user-configurable with a maximum value of 65,535.
The default for the Preset is 2.

Value

Timebase

0

1 ms

1

10 ms

Value

Preset

User Configurable

2 – 65,535
