Chapter

3

Installation and Mounting

Chapter Objectives

This chapter describes how to install and mount a standard or custom
DeviceNet

™ Pendant Station. It contains the following sections:

DeviceNet

Guidelines

It is your responsibility to install and implement the DeviceNet

Network and supported devices according to the DeviceNet

guidelines.

Equipment Needed

There is no need to open the enclosure. The only tools required are for
installing a hanging cable.

Setting the Data Rate

This device contains Autobaud functionality, it will automatically
detect the network data rate and synchronize to it.

The data rate determines the maximum length of the DeviceNet

Cable.

Section

Page

DeviceNet

™ Guidelines

3-1

Equipment Needed

3-1

Setting the DeviceNet

™ Node Address

3-2

DeviceNet

™ Pendant Dimensions

3-3

Hanging the Pendant Station

3-4

Recommended Strain-Relief Method

3-4
