Rockwell Automation Publication 440G-UM001A-EN-P — November 2013 33
Specifications Appendix A
Switch Mounting Bracket 440G-LZAM2
6.35
(0.25) 54
(2.12)
40 (1.57)
R6
+1
-3
3x 5.5
(3x 0.22)
145.5
(5.72)
4x R6
± 1 mm
2x 15
(2x 0.59) 2x 33
(2x 1.3)
6x M5
x 0.8-6H
2x 31.5
(2x 1.24)
3 x 5.5
(3x 0.22)
2x 15.5 (2x 0.61)
18.5
(0.73)
2x 6.35
(2x 0.25) 22.75 (0.89)
100 (3.93)
