Status/Diagnostic LEDs
During Operation During operation, the LEDs indicate the status of the Guardmaster
440G-LZ guard locking switch as follows:
Power-to-Lock
Versions Guard
Status Lock
CMD OSSD
Input Lock
Status LED
Status OSSD
Status
Power on and lock
CMD off Open or
closed Off Off or
on Unlocked Blinks 6x green
then solid red
Off
Lock CMD on, door
open Open On Off or
on Unlocked Fast flash green Off
Lock CMD on, door
closed Closed On Off Locked Slow flash green Off
Lock CMD on, door
closed Closed On On Locked Solid green On
Power-to-
Release Versions Guard
Status Lock
CMD OSSD
Input Lock
Status LED
Status OSSD
Status
Power on with
door open Open Off Off or
on Unlocked Blinks 6x green,
then blinks 1x
red, followed by
fast flash green
Off
Power on with
door closed Closed Off Off Locked Blinks 6x green,
then blinks 1x
red, followed by
slow flash green
Off
Power on with
door open, and
OSSD input active Closed Off On Locked Blinks 6x green,
then blinks 1x
red, followed by
solid green On
Unlock CMD on,
and door closed or
open Open or
closed On Off or
on Unlocked Solid red Off
