Product Overview
This chapter contains the following information:
•
The physical layout of the module.
•
Location of configuration switches.
•
Overview and components.
Module Description
The PD1 Module is an optional interface device designed to provide a
direct, digital link between a Profibus Master and the 160 Drive. The
module connects to the drive through the expansion/keypad port on
the front of the drive. Refer to Figures 1.1 and 1.2 for general layout
of the module and Chapters 4 or 8 for details on the LED indicators.
Figure 1.1
Module Front View
9 Pin, Female D-Shell Connector
Refer to Chapter 3 for Details
Module Installation Latch
Status LEDs
Refer to Chapters 4 & 8
for Further Information
Nameplate
Provides Firmware Version
and Series Letter
