Steriflow Mark 978INLINE Series - Manual (Page 9)

B
A C
D
Valve
Size
Dimensions
Weight
Kgs A B C D
DN40 211 432 24,4
318 (55M) 22 (55M)
381 (85M) 27 (85M)
DN50 260 438 24,4
318 (55M) 22 (55M)
381 (85M) 27 (85M)
1-1/2" & 2" v
alve
s
ize
Valve
Size
Dimensions
Weight
Lbs A B C D
1-1/2" 8.31 17.00 0.96
12.50 (55M) 49 (55M)
15.00 (85M) 59 (85M)
2" 10.23 17.25 0.96
12.50 (55M) 49 (55M)
15.00 (85M 59 (85M)
-9-
M
ark
978 S
anitary
G
lobe
-S
tyle
C
ontrol
V
alVeS
- J
orlon
D
iaphraGM
S
eal
inline D
imensions
Flow
Based on US tri-clamp ends. Consult factory for DIN and ISO tri-clamp
end dimensions
i
nches
m
etric
Installation Orientation and Drainability:
• Valve has not hold-up when installed as shown above, but must be drained below inlet.
