JSRLF S
eRieS
L
ow
F
Low
P
ReSSuRe
R
educing
V
aLVe
o
rDering
s
chematic
Model
Size
Material
/
1 & 2 3 & 4 5 & 6 7 & 8 9 & 10 11 & 12 13 & 14
15
16
17
—
—
Model
JSRLF
Low Flow Pressure Reducing Valve
Size
025
1/4" (DN08)
038
3/8" (DN10)
050
1/2" (DN15)
Material
6L
ASTM A479, 316L
1 & 2
Body Feature
End Connection
Port Configuration
A
FNPT, 1/4"
A
Port "A"
B
FNPT, 3/8"
B
Port "B"
C
FNPT, 1/2"
C
Port "C"
T
ASME BPE Tri-Clamp, 1/2"
D
Port "D"
W
ASME BPE Tube Weld, 1/2"
E
Port "E"
S
1
ISO Tri-Clamp, DN15
D
2
DIN Tri-Clamp, DN15
M
3
DIN Tube Weld, DN15
P
4
ISO Tube Weld, DN15
ZZ
Non-Standard
1
Acc. to DIN 32676 Row B (ISO 1127). See dimensions, page 3
2
Acc. to DIN 32676 Row A (DIN 11850). See dimensions, page 3
3
Acc. to DIN 11866, DIN 11850 Row A
4
Acc. to DIN 11866 Row B, (ISO 1127)
3 & 4
Trim
1S
Cv 0.012
2S
Cv 0.08
3S
Cv 0.2
4S
Cv 0.03
1R
Cv 0.012 Self-Relieving
2R
Cv 0.08 Self-Relieving
3R
Cv 0.2 Self-Relieving
4R
CV 0.03 Self-Relieving
ZZ
Non-Standard
5 & 6
Seat Material - FDA & USP Class VI
T1
PTFE Cv 0.012
P2
PEEK Cv 0.08
T2
PTFE Cv 0.08
P3
PEEK Cv 0.2
T3
PTFE Cv 0.2
P4
PEEK Cv 0.03
T4
PTFE Cv 0.03
ZZ
Non-Standard
P1
PEEK Cv 0.012
7 & 8
Range Spring / Outlet Pressure
E1
5 - 50 psi
E5
100 - 450 psi
E2
25 - 100 psi
E6
200 - 750 psi
(NPT only)
E3
50 - 150 psi
E4
75 - 250 psi
ZZ
Non-Standard
9 & 10
Diaphragm Material
JL
Jorlon
TM
PTFE, FDA & USP Class VI
ZZ
Non-Standard
11 & 12
Actuator
SK
Standard Actuator
AK
Autoclavable Anodized Aluminum Knob available
as cataloged option
CV
Captured Vent
PM
Panel Mount
TP
Anti-tamper feature (See illustration page 3)
ZZ
Non-Standard
13 & 14
Inlet Gauge
AA
0 - 30 psi / bar
(Dual)
HH
0 - 600 psig/bar (Dual)
NPT only
BB
0 - 60 psig / bar
(Dual)
JJ
0 - 1000 psi/bar (Dual)
NPT only
CC
0 - 100 psig / bar
(Dual)
KK
0 - 2000 psi/bar (Dual)
NPT only
DD
0 - 160 psig / bar
(Dual)
LL
0 - 3000 psi/bar (Dual)
NPT only
EE
0 - 200 psig / bar
(Dual)
MM
0 - 5000 psi/bar (Dual)
NPT only
FF
0 - 300 psig / bar
(Dual)
NN
None
GG
0 - 400 psig / bar
(Dual)
ZZ
Non-Standard
15
Outlet Gauge
A
0 - 30 psig
B
0 - 60 psig / bar (Dual)
C
0 - 100 psig / bar (Dual)
D
0 - 160 psig / bar (Dual)
E
0 - 200 psig / bar (Dual)
F
0 - 300 psig / bar (Dual)
G
0 - 400 psig / bar (Dual)
H
0 - 600 psig / bar (Dual) NPT only
J
0 - 1000 psi / bar (Dual) NPT only
N
None
Z
Non-Standard
16
SEP Compliance
G
SEP Compliant
Ø
None
Z
Non-Standard
17
Accessories
S
Clean For Oil Free
X
Clean For Oxygen
Ø
None
Z
Non-Standard
