Hardware Bag Breakdown:
HB-T421 Lift Hardware
ITEM# dESCRIPTION qTY
38X2FTB 3/8 X 2 FINE THREAD BOLT, GR8 4
516X1FTB 5/16 X 1 FINE THREAD BOLT 6
12X112FTB 1/2 X 1 1/2 FINE THREAD BOLT 3
12X214FTB 1/2 X 2 1/4 FINE THREAD BOLT 1
12X212FTB 1/2 X 2 1/2 FINE THREAD BOLT 1
58X212FTB 5/8 X 2 1/2 FINE THREAD BOLT 2
58X412FTB 5/8 X 4 1/2 FINE THREAD BOLT 4
38FTN 3/8-24 FINE N/I LOCK NUT 4
516FTN 51/6-24 FINE N/I LOCK NUT 6
12FTN 1/2-20 FINE N/I LOCK NUT 5
58FSFTN 5/8-18 FLANGE STOVER NUT 2
58FTN 5/8-18 NYLON INSERT LOCKNUT 4
38SAEW 3/8 SAE WASHER 11
516SAEW 5/16 SAE WASHER 14
12SAEW 1/2 SAE WASHER 6
TS250 TOY SLEEVE,IFS .250" LONG 1
TS875 TOY SLEEVE,IFS .875" LONG 1
TS1125 TOY SLEEVE,IFS 1.125" LONG 1
TTS34 TOYOTA TAPERED SLEEVE, 3/4" 2
T4LSP TOY 4" LOCATING SPACER 8
BPBN BUMP STOPS, BUTTON SHAPE 4
LT100 THREAD LOCK COMPOUND 1
Kit Box Breakdown:
T421R:
ITEM# dESCRIPTION qTY
RB35 3.5" REAR BLOCK 2
916X212X1012 1 U-BOLT WITH NUTS 4
Note: T421RS will not consist of lift blocks and the rear u-Bolts will be part # 916x212x7
T431R:
ITEM# dESCRIPTION qTY
RB35 3.5" REAR BLOCK 2
916X318X912 1 U-BOLT WITH NUTS 4
Note: T431RS will not consist of lift blocks and the rear u-Bolts will be part # 916x318x812
IT422/432 Pg 3
