Kit Box Breakdown:
T422:
ITEM# dESCRIPTION qTY
T4SP-B TOY 4" SKID PLATE BRACKET 1
401-L TOY 4" SPINDLE - LEFT 1
401-R TOY 4" SPINDLE - RIGHT 1
T4FCM-B TOY 4" FRONT A-ARM CROSS MEMBER 1
T4RCM-B TOY 4"REAR A-ARM CROSS MEMBER 1
T4DDB-B TOY 4" DRIVER DIFF DROP BRKT 1
T4CDB-B TOY 4" CENTER DIFF DROP BRACKET 1
T4PDB-B TOY 4" PASS DIFF DROP BRACKET 1
T4BP-B TOY 4" BUMP STOP SPACER BRACKET 4
T4SBL-L TOY 4" SWAY BAR LWR BRKT-LEFT 1
T4SBL-R TOY 4" SWAY BAR LWR BRKT-RIGHT 1
BK-T421 BRAKE LINE HARDWARE 1
HB-T421 KIT HARDWARE BAG 1
Hardware Bag Breakdown:
BK-T421 Brakeline Hardware
ITEM# dESCRIPTION qTY
TFBE-2 TOYOTA FRONT BRAKE LINE EXTENSION 2
TRBE-1 TOYOTA REAR BRAKE LINE EXTENSION 1
T4RPV-B TOY 4"REAR PROP.VALVE BRACKET 1
38X1FTB 3/8 X 1 FINE THREAD BOLT 3
516X1FTB 5/16 X 1 FINE THRD BOLT 2
38FTN 3/8-24 FINE N/I LOCK NUT 3
516FTN 51/6-24 FINE N/I LOCK NUT 2
38SAEW 3/8 SAE WASHER 3
516SAEW 5/16 SAE WASHER 2
Pg 2 IT422/432
