Skyjacker NBP103 - Manual

Before beginning the installation, thoroughly & completely read these instructions. Please refer to
the Parts List to insure that all parts & hardware are received prior to the disassembly of the vehicle.
If any parts or hardware are found to be missing, contact SKYJACKER® Customer Service at
318-388-0816 to obtain the needed items. If you have any questions or reservations about installing
this product, contact SKYJACKER® Technical Assistance at 318-388-0816.
2013 Polaris Ranger 900 XP
Nerf Bars
Installation Instructions
RequIRed Tool lIsT:
• safety Glasses
• Jack / Jack stands
• standard Wrenches & sockets
• drill & Assorted drill Bits
• Jig saw
• Torque Wrench
www.skyjacker.com
I-NBP103 8-14 Pg 1
Component Box Breakdown:
Part #: NBP103
Hardware Bag Breakdown:
Part # HB-NBP103
Item # description qty Item # description qty
516X1FTB 5/16 X 1 FINE THREAD BOLT 4 516X34TCFB 5/16 X 3/4 THRD CUT FLG BOLT 2
516SAEW 5/16 SAE WASHER 8 38X1TCFB 3/8 X 1 THRD CUT FLG BOLT 6
516FTN 5/16 FINE THREAD LOCK NUT 4
Item # description qty Item # description qty
P13NB-L 13 POL RGR XP LFT BAR 1 HB-NBP103 HDWR BG: NBP103 NERF BAR 1
P13NB-R 13 POL RGR XP RGT BAR 1 I-NBP103 INST SHEET: NBP103 1
